Personal notes on Implementing autoPublishing mechanism to custom DB table within modx3.

A need.

  1. I have a custom database setup inside my modx3 install. Recently I started to think of adding a auto-publishing feature for this database, just as the modx3’s siteContent table is capable of doing.

Pre-requisite and assumptions.
1. MODX3 installation
2. Custom database table inside the MODX installation, which is created from modx database schema. I used migx’s package manager to create/modify one.
3. Let’s say that the class name of this dbtable is /MyDB/Model/Mydb
3. A custom table schema for modx to construct the table and associated code structure needs the following fields added to the schema. Note the data type for those date fields are all datetime. and not int(20) like original siteContent table fields for page resource. The difference will be dealt in the implementation code.

<field key="published" dbtype="tinyint" precision="1" attributes="unsigned" phptype="integer" null="false" default="0" />
<field key="publishedon" dbtype="datetime" phptype="datetime" null="true" />
<field key="pub_date" dbtype="datetime" phptype="datetime" null="true" />
<field key="unpub_date" dbtype="datetime" phptype="datetime" null="true"/>

4. The auto-publish mechanism will mimic the existing code for modResource autopublishing mechanism. This reference code lives in core\src\revolution\modcachemanager.class.php. (for MODX2, the file is in core\model\modx\ folder)

5. The function I want is to toggle the record’s published flag based on records’ pub_date and un_pub date. It is still my implementation code (snippets) to filter records based on this flag to display data in the web site.

Two code segments have been written. The first is auto publishing functionality. The code heavily borrows from the aforementioned built-in autopublishing code, which is for page resources.

<?php
/**
 * @var $modx object
 * this code first check if auto_publish.cache.php returns the timestamp that is smaller than now timestamp.
 * if so, then there is at least one Mydb record that need to be acted on (either publish or unpublish))
 * and calls autopublish_mydb().
 */
/* first, check the cache value and compare it to current time */
$options = array(XPDO::OPT_CACHE_KEY => 'my_db');
//With this option, cache file is in /core/cache/my_db folder

$actionNeeded = $modx->cacheManager->get('auto_publish', $options);
$timeNow = time();
//No action is taken if cached timestamp is zero or bigger than today's timestamp, except when timestamp does not exist (null)
if (($actionNeeded>0 && $actionNeeded < $timeNow)  || $actionNeeded===null) autoPublish_mydb($modx, $options);

/** * @param $modx
 * @param array $options
 * @return void
 * this function check the Mydb table and alter record's published status.
 * if pub_date is less than current timestamp, and published is false then the record will be published and publishedon data
 * updated, and pub_date will be set to null
 * if unpub_date is less than current timestamp, and published is true then the record will be unpublished and publishedon date
 * and unpub_date will be set to null
 * record is scanned for new unpub/pub_date and cache file is refreshed.
 */
function autoPublish_mydb($modx, array $options): void
{

    $tblResource = $modx->getTableName('MyDB\Model\Mydb');

    $timeNow = time();  //get timestamp number of current date/time

    /* publish and unpublish resources using pub_date and unpub_date checks */
    $modx->exec("UPDATE $tblResource SET published=1, publishedon=pub_date, pub_date=NULL WHERE pub_date IS NOT NULL AND unix_timestamp(pub_date) < $timeNow");
    $modx->exec("UPDATE $tblResource SET published=0, publishedon=NULL,unpub_date=NULL WHERE unpub_date IS NOT NULL AND unix_timestamp(unpub_date) < $timeNow");

    /* update publish time file */
    $timesArr = array();
    $stmt = $modx->prepare("SELECT MIN(unix_timestamp(pub_date)) FROM $tblResource WHERE published = 0 AND unix_timestamp(pub_date) > 0");
    if ($stmt->execute()) {
        $value = $stmt->fetch(PDO::FETCH_NUM); // MIN operator query will return only one row. query is asking for only one column
        if ($value[0]) $timesArr[] = $value[0]; // that column is either empty or value. If value exists, push into array.

    }
    $stmt = $modx->prepare("SELECT MIN(UNIX_TIMESTAMP(unpub_date)) FROM $tblResource WHERE published = 1 AND UNIX_TIMESTAMP(unpub_date) > 0");
    if ($stmt->execute()) {
        $value = $stmt->fetch(PDO::FETCH_NUM);
        if ($value[0]) $timesArr[] = $value[0];

    }

    $nextEvent = (count($timesArr) > 0) ? min($timesArr) : 0;//select younger of timestamps if these exist. Otherwise, $nextEvent=0;
    /* cache the time of the next auto_publish event */
    $modx->cacheManager->set('auto_publish', $nextEvent, 0, $options);
}

Some points to note.

  1. dbtype for these dates are datetime. In original code, they are integer(timestamp).   MySql function unix_timestamp() is used inside the query to  convert them as needed.
  2. The function return type is changed from array to void. I thus removed all return values construction as I could not think of any use case in my usage scenario.
  3. This code, when invoked will fetch the cache file /core/cache/my_db/auto_publish.cache.php. The file will return a timestamp value or 0 or null. The location of the cache file is defined in $options array and separate from the system’s auto publish cache file.
  4. if timestamp returned is less than current timestamp but not 0 or timestamp returned is null (meaning there is no cache file) then it proceeds to auto_publish function Otherwise it will return without doing anything.
    1. Auto publishing function will do the following. They are basically two pdo queries.
      1. Publish all record that’s pub_date is less than current time, unset pub_date, set publishedon to pub_date.
      2. Unpublish all record that’s unpub_date is less than current tme. unset unpub_date and unset publishedon date
      3. set new cache value to minimum of remaining unpub_date and pub_date sets.
    2. In the original code, Unpublishing query is resetting both unpub_date and pub_date. I can not see any side effects on not unsetting pub_date so I left it out.

Now, when to invoke this code? The original Resource auto_publishing code is invoked whenever resource is accessed.

I originally added the code as a snippet to my site’s landing page so that the code will execute whenever somebody visit my site. But I also wanted to tryout the plugin functionality, so I saved the code as a plugin and named the plugin refresh_pub_date

Then in the system’s settings, I created a custom event. myCustomeEvent and enabled the refresh_pub_date plugin to this event.

The following code will invoke this event. So my snippet in the landing page is just that.

$modx->invokeEvent('refresh_pub_date',array())

Second code is used to check for pub_date, unpub_date after record save/update

<?php
/**
 * afterSave snippet for Mydb (migxdb configurator setup  'snippethook')
 *  the snippet will update auto_publish timestamp for the custom table
 * if unpub or pub date is smaller than the value already cached.
 *
 * migx provides the following variables
 * @var $modx object modx runtime object
 * @var $object object  object of the class being handled
 * @var $postvalues  array of posted values
 * @var $scriptProperties  mixed parameters, Includes all of the above.
 */

$result = '{"error":"","result":"success"}';
$options = array(XPDO::OPT_CACHE_KEY => 'my_db'); //define folder name for cache file
$timesArray = [];
$pub_date_ts = strtotime($postvalues['pub_date']); //retrieve pub_date datestamp
// the value is also retrievable from $object.  ie., strtotime($object->get('pub_date'));
if ($pub_date_ts) {
    $timesArray[] = $pub_date_ts;
} //push pub_date to times array if exists. boolean evaluation of the variable returns
// false if $pub_data_ts is empty, null, 0 or false

$unpub_date_ts = strtotime($postvalues['unpub_date']);
if ($unpub_date_ts) {
    $timesArray[] = $unpub_date_ts;
} // push unpublish date timestamp to the times array if exists

$current_ts = $modx->cacheManager->get('auto_publish', $options);
if ($current_ts === null and count($timesArray) == 0) {//In case of no cache file, meaning  the file is manually deleted somehow.
    $current_ts = time(); //set the time so auto_publish logic will run once and will set correct time if pub/unpub already existed.
    $modx->cacheManager->add('auto_publish', $current_ts, 0, $options);
}

if (count($timesArray) > 0) { //rewrite timestamp only if new TS is younger or the  current one is 0. Don't write otherwise
    $new_candidate_ts = min($timesArray);
    if ($new_candidate_ts < $current_ts || $current_ts === 0) {
        $modx->cacheManager->replace('auto_publish', $new_candidate_ts, 0, $options);
    }
}
return $result;

This code will be invoked when Mydb record is added/updated. Since I use migxDB to create a CMP for this DB table in the manager, migxDB custom configurator allows the easy way to attach the snippet to after save action.

{"aftersave":"mySnippet"}

If called this way, migxDB provides $postvalues array variable to allow access to posted data field that is needed to be convert to timestamp like so.

strtotime($postvalues['unpub_date']);

It also provides $object variable for the class object (including record fields that are not posted) So the same value can be retrieved with usual get method.

strtotime($object->get('unpub_date'))

Note: If I don’t use migxDB CMP configurator and write my own class processors extended from MODX processors, retrieval of the same value in aftersave hook in the update processor would have been

strtotime($this->getProperty('unpub_date'))

There was a bonus take away from this project

  1. I learned how to use MODX Cache file system. The main purpose of using the cache files must be obviously to eliminate a need of re-running of various codes on server side. However I can also do things like the following to record values of variables into the cache file for debugging purpose.

$options=array(XPDO::OPT_CACHE_KEY=>'debugstore');
$myvalues=print_r($varToCheck,true);
$modx->cacheManager->set('myVarvalues',$myvalues,0,$options);

TV Japan から JMEへ

北米に住んで、長年にわたり親しんできたTVJapanがサービスを2024年3月31日で終了した。 NHKの番組をメインに、民放の番組もちりばめ、NHKの番組の合間にコマーシャルが入るという不思議な環境ではあったが、日本のニュースを見る時など、それなりに重宝していたし、日本のドラマなども楽しめていた。

時の流れというのは止められないもので、NetFlixやPrimeなどで日本のコンテンツもかなりの量が米国からみられるようになり、さらにNordVPNやら、ExpressVPNなどのVPNサービスを使ってあたかも日本からのアクセスしているように見せかければ、本来は海外からは見られないようなコンテンツもこれらのサービスで視聴可能。こういう術に長けたものにとっては従来のTVサービスの重要性は失われていくものなのだろう。

TVJAPANの場合、終了のお知らせは多分2か月くらい前からはじまり、かなり急な話ではあった。 それに代わるサービスとしてJMEというストリーミングサービスが新たに始まった。 3つの24時間チャンネル。 さらに人気ドラマやバラエティなど選ばれたメディアソフトの配信サービスということで、かなり充実しているはずなのだが、TVJapanを見なれてきたものからするとかなり不便に感じる。

何故か。 録画予約ができないんである。

考えてみれば当たり前のことで、今までも録画予約機能はTVJapanが提供していたわけではなく、 TVJapanのチャンネルを供給していたケーブルサービスのDVR機能を使っていたわけだ。 だからJME自体に録画機能がないと文句をいうのはお門違いなわけだが、やっぱり不便である。

もちろんいいこともあって、月額の料金は5ドル下がったし、そもそもTVJapanを入れるためにはケーブルサービスのTVバンドルでのプレミアパッケージを購入しなければいけなかったので、これを解約してベーシックパッケージにしたら、ケーブル局への支払いも60ドル下がったんである。 よって、TAX入れれば月70ドル近い節約になり、なんでこんな金額を今まで払っていたのか、と思わなくもないわけだ。

チャンネルの一つNHKワールドプレミアムは日本のNHKの配信をそのまま流している。もう一つのNHKワールドは外国人向けのNHK放送なので英語が主体。 三つ目のチャンネルはJMEセレクトで、今のところ、同じ番組の組み合わせを6時間ごとに毎日4回放映している。JMEセレクトはニュース7以外のニュースは番組表に入っていないので、ワールドプレミアムを見るしかないのだが何せニュース番組なので見るチャンスが一回しかない。 以前は録画して後でも見れたのだが、今は時間を合わせてみるしかない。

AmazonのFireStickをTVに差し込んでみている場合はFireStickの8GBのメモリーを使って同時録画は可能。

PCやアンドロイド、あるいはIOSデバイスでのストリーミングサービスの録画というのは検索すればいくらでも出てくるが基本的には画面キャプチャーの機能だから、その場での”録画”はいくらでもできる。 ただし、録画予約ということになると、デバイスは最初からオンにして放映しっぱなしの状態での時間を指定してそこからの録画というのはできるとして、JMEアプリを起動してチャンネルを合わせ、キャプチャー開始となると、そんな機能のアプリってあったっけ、という話になる。 やろうと思えば、自分でも作れなくはないという気はするが、APIのとか認証のやり取りの解析の手間を考えるとそこまでのモチベーションはない。

一番良いのは例えばHULUのliveTV で用意されているCloud DVR on HULUなどのような機能をJMEが追加してくれることだと思うが、そういう風に進化してくれないかな?

大昔、まだVCRなんてものが無かった時代は6時から始まる「○○○○○○」が見たくて、大急ぎで部活を切り上げ自宅に戻っていたなんてことがあったようななかったような。 そんな時代に逆戻りしたような感覚。

一方、On demandの部分、見始めて話が面白いと「不適切にもほどがある」をまとめて全話みてしまう(BINGE Watchというらしい)という暴挙をついやってしまうという健康上非常に不適切な行為におよんでしまい、 配信サービスに対する距離感を決めておかないと非常にまずい、と思い始めた今日この頃です。

array_reduceの話2

array_reduceと arrayのsplat オペレーターを使うと、同じアレーを生成するという意味のない関数ができる。

$source_array=[3,2,4,5];
$nop_array=array_reduce($source_array, fn($carry,$item)=>[...$carry, $item],[]);
print_r($nop_array); //array=>[3,2,4,5]

で、パターンを使って、array_mapもarray_filterもarray_reduceで代用できるというお話



// array reduce to mimic array_map
$source_array=[3,2,4,5];
$double=function($x){
    return $x*2;
};
$mapped_array=array_reduce($source_array,fn($carry,$item)=>[...$carry,$double($item)],[]);

print_r($mapped_array); //array=>[6,4,8,10]

//array reduce to mimic array_filter

$even_fn= function($x){ //return true if even
   return ($x % 2)==0;
};


$filtered_array=array_reduce($source_array,
    fn($carry,$item)=>$even_fn($item)?[...$carry,$item]:$carry,
    []);


print_r($filtered_array); //array=>[2,4]


めでたし、めでたし

array_reduceの話

PHPでプログラミングするとき、例えば、以下のようなアレィがあったとする

$fields=array("a"=>"A", "b"=>"B", "c"=>"C", "d"=>"D")

この内容をキーとともにリストアップしたいとき、まず思いつくのがforeachを使ってこう書く方法

$output="<h3>listing array with foreach</h3>";
foreach($fields as $key=>$value){
    $output.="<pre>".$key.":"$value."</pre>"
}
echo $output;

ただ、このアレィの複数エレメントを一つの値(この場合は一つの文字列)にまとめるという風に考えるとarray_reduceという関数を使っても同じことができる

$output="<h3>Listing array with array_reduce</h3>";
$output=array_reduce(array_keys($fields),fn($curry,$item)=>$curry."<pre>".$item.":".$fields[$item]."</pre>",$output
);
echo $output;

この関数、単純なArray処理は問題ないとして、Associative Arrayを処理するとなると、はたと困るが、渡すArrayを値ではなく、キーを渡すことで可能となる。これは一つ目の因数にarray_keysを使うことで実現できる。コールバックには因数が二つ付くが、慣習として$curry と$itemという変数名を使う。for 文に$iをつかっているのと同様で、もちろんほかの変数名としても問題ない。$curryは結果を集積していく入れ物。$itemはアレィの各エレメント。上の例ではコールバック関数はアローファンクションを使ってインラインの書き込み。 三つ目の因数($output)は初期値

このarray_reduceの使いかたをネットの検索などで探すと、数字を加算していくような例がよく紹介されているが、上のように文字列アレィの加工にも有効。 さらに、このアレィは関数のアレィでもよいわけで、例えば、複数の関数で同じ文字列の処理を繰り返すような場合、例えば、文字列をトリムしあとhtmlにエンコードしたい場合など、つまり同じ文字列に何度もパスをかけて加工したい場合など

$output=trim($output);
$output=htmlspecialchars($output);
//または
$output=htmlspecialchars(trim($output));

のかわりに

$output= array_reduce([trim,htmlspecialchars], fn($curry,$item)=>$item($curry),$output)

と書いてしまう技がある。関数が二つなら最初のアプローチのほうがよさそうだが、かかわる関数が増えてくると、コードのメンテナンスは下のパターンのほうがすっきりするよ、とFunctional Programmingの推進者たちはいっているが、さてどうする。

$functionsArray=[fn1,fn2,fn3,fn4,fn5]; //同じオブジェクトに対し、5つの関数処理をおこないたい
$result=array_reduce($functionArray, fn($curry,$item)=>$item($curry),$initialValue);

“Why did I not think of this?” moment in MODX 3 snippet development with PHPStorm

This is one of those ‘Aha!’ moments.

MODX is one of CMSs (content management system) that I have been using for a long time to maintain my shogi site. Market penetration of this CMS is said to be 0.1%. As of this writing, 43% of of Web sites uses WordPress and no other CMS reach even 10% of market share. (source, w3techs.com . I actually think MODX penetration is much greater than this number, MODX does not leave big footprint to show it’s identity in front of web crawlers. -Many sites I know powered by MODX, including mine – were identified as non-CMS site by w3tech’s tool.— Nevertheless, there is no doubt WordPress dominates the CMS market)

Although both uses same language (PHP) for powering the site, MODX gives much more flexibility in site design but you need to be proficient with HTML and CSS (and JavaScript). In another word, MODX is a tool while WordPress is a product.

What I liked about MODX over WordPress at the time was a separation of PHP code and HTML. This was a long time ago so the situation might have changed on WordPress, but I have been happy with MODX since.

At the time, I also looked at Drupal and Joomra . All of them forces you to follow their interpretation of what website should be. MODX has no opinion on how you want to create Web site. You have a total freedom.

On the other hand, if the only thing you want to do with your site is blogging, there is no better solution than using WordPress.

I digressed. Back to the subject!

With a wealth of plug-ins available, your rarely need to code in PHP. When you do though, MODX separates a PHP coding part from HTML with a thing called Snippets. A snippet is then inserted in to HTML with a use of tag.

[[aSnippet]]

You can edit a snippet within MODX backend’s editor. With a plugin like ‘ACE’ there is a nominal amount of syntax checking to the PHP code. Unfortunately, I am being spoiled with convenience of IDE such as PHPStorm,

MODX backend, Snippet editor with ACE plugin

So there is a desire to be able to write a snippet code using PHPStorm and get benefits of auto-completion and methods hinting, strict error checking and warning.

Unfortunately, there is no plugin in PHPStorm for MODX or MODX plugn for PHPStorm.

When I google “MODX with PHPStorm”, there are several hits, Although none of them gave me a direct answer on what I wanted to do, I was able to put enough facts together and came up with a solution. The solution that was just waiting for me to assemble few known facts, that I have used all of them separately in the past!


1. Fact that PHPstorm can create a project using existing remote site contents, so that PHPStorm can pull all file setup from MODX site.

PHPStorm->File->New Project from Existing Files


2. Fact that PHPstorm can then start syncing file contents of my local project files to server files.

File sync options available in PHPStorm

Ok, but Snippet is stored in Database. the code is not in the file, but then,

3. Fact, MODX snippet code can be from a static file, meaning I can create a PHP file and feed it as a snippet to MODX by turning on “is Static” option and point to the file location

Is Static option is turned on for Snippet. Snippet is now fed from “static file”



Result: When I combine those 3 factors, I can create a snippet with a comfort of PHPStorm IDE environment.

Snippet now editable in PHPStorm
Snippet output on browser page, powered through MODX

What do I gain? Full context support and code hinting, as PHPStorm analyzes whole MODX site and figures out all variables and object and its methods being used inside MODX. I have to give credit to MODX development team for fully documenting source files. Thank you!

PHPstorm explains what getOption method is
PHPStorm autocomplete support in action.

You can also open the corresponding file by pointing to method and do control-b to drill down on function.

I edit a file in PHPStorm, and you either 1) turn on auto-sync between your local files and server files or 2) manually upload changed file to server. Then I can run and test the snippet with MODX backend immediately.

So all of the sudden, I feel like invincible. It will be very hard for me to make coding error. (Ok, logic error still possible)

Once Snippet development is done, you may switch off the ‘is static’ option and keep the snippet inside database, remove the php file from the system.

One thing that is kind of annoying is that by default, PHPstorm thinks $modx variable is undefined. The default setting on PHPStorm’s inspections on undefined variable is somewhat on conservative side. It will not even acknowledge variables from included file!. To mitigate this, you need to put a check on “Search for variable’s definition outside the current file”

PHP settings->Editor->Inspection->PHP->Undefined symbols->Undefined variable

It hurts to think that I have been using both PHPstorm and MODX for more than 10 years and I am figuring this out just now 🙁

Creating a Blog page inside MODX version 3 web site

MODX comes clean slate so there is no ‘ready to use’ provisions for creating Blog style site. One has to set it up using tools available in the CMS.

I took an easy way out for my production site by creating blog site using free wordPress service and then feed content to MODX page. with this, the only extra you will need is Spiefeed to handle rss feed from WordPress.  But for purist approach it is certainly possible to setup blog section within MODX using few extras.

There are several articles available for creating Blog sites using MODX.  The one shown in the modx official site is somewhat dated, but the article actually have a link to the instruction/article of more recent implementation of MODX blog site.  Link is here.   Better yet, this instruction is accompanied with a package published in the github which has all chunks, a snippet and a template packaged up to duplicate the blog site that the article discusses.  A demo site is also available to check out the feel of using this template. The document states that the demo utilizes MODX 2.7.  So can I use this setup with MODX 3 site? Furthermore, the instruction assumes you want the Site to be a blogging site. Can I add ‘Blog page’ to already existing MODX site? Answer to both questions are ‘Yes’ but we need to modify some parts.

To start, I could have created each chunk and template manually following the instruction but to reduce my typing effort, I went ahead and downloaded the demo package. I also installed dependent extras (getResources, getPage, Collections, and Tagger).  Previously, I did not have any of those installed. – I am using pdoTools  to get resources and get page. – <edit> It was fairly easy to change references to getResources and getPage to equivalent pdo* snippets.

Again, the setup instruction is written for MODX version 2.7 and the site I am setting up this blog structure is version 3.0.3.  Setup also assumes the top page is a site home page. There are several area in chunks and template that refers to [[++site_start]] and this need to be changed to point to correct Resource.  I want to have a blog page as a subpage of the site.

Looking through the template and snippets that I setup with the downloaded package , I found some more modifications were needed.

I will list out those changes.

  1. My server uses Nginx and it needs additional html tag to specify base url in <head> section of blog template html. Without it, Friendly URL won’t work correctly.
    <base href="[[++site_url]]">
  2. In MODX 3, [[*class_key]] does not return “modResource”.  It returns “MODX\Revolution\modResource”.
    This means I get “MODX/Revolution\modDocument” or “MODX\Revolution\CollectionContainer” in [[*class_key]] field depending on resource selected. Two sections of “Blog Template” stops working due to this.

    1. Template tries to pull in “jumbotron_CollectionContainer” or “jumbotron chunk based on [[$jumbotron-[[]*class_key]]] tag. This tag doesn’t work in MODX 3 as it returns [[$jumbotron-MODX/Revolution/….]] which does not exist and forward slash within chunk name is probably invalid anyway.
    2. Template tries to insert [[$blog_listing]] or [[$blog_article]] based on conditional modifier [[*id:is`[[++site_start]]`:then….]] but the blog_listing page is not at [[+site_start]] resources in my use case.
      1. To mitigate both problems, I have created a system setting [[++blog_start]] in custom namespace/area and set it to id of a blog home page resource I created. Then rewrote tags as follows.
        For jumbotron section
        [[[[*id:is=`[[++blog_start]]`:then=`$jumbotron-CollectionContainer`:else`$jumbotron-modDocument`]]]]
        For container section
        [[[[*id:is=`[[++blog_start]]`:then=`$blog_listing`:else=`$blog_article`]]]]
      2. Note: It will be probably not that difficult to create snippets and replace conditional tags here.
  3. getResources and getSnippet tags are used to aggregate child resources and parents properties are set to site home page [[++site_start]].   These needed to be changed to aforementioned [[++blog_start]].  These changes had to be made on $blog_listing chunk and $jumbotron-CollectionContainer chunk.
  4. @groups properties are hardcoded in calls to TaggerGetTags snippet.  The snippet is called from $aside chunk is setting @groups to 1 and the snippet called from $headder chunk is setting @groups to 2.  Make sure this agrees with your tagger group settings. I have first created ‘Category’ group and then ‘Archives’ group so I needed to change them to 2 and 1 respectively.
  5. Last and least 🙂   as this is just a demo template, links to “subscribe”, “search”, “Sign up”, “GitHub”, “Twitter” and “Facebook” are all mocked and pointing to itself.  You either need to remove or put actual link to them when modifying to suit your site design.

So, in order to create a Blog section within Modx 3 hosted website, using this instruction and elements in the github repo, One needs to be aware of:

  1. Modx version 3’s breaking change of the model class caused decision logics inside Blog_Template to stop working.  Rework of the logic flow was needed.
  2. Friendly url.  Nginx needs base href reference in head section.
  3. Creating a blog section other than home page location. Needed to change references to [[++site_start]] system settings to [[++blog_start]], a user created system setting
  4. Adjust the template design to fit with other area of site design.

Some more miscellaneous items to note.

  1. $blog_listing_item chunk, content placeholder has a modifier :firstp. There is a firstp snippet that is installed with the package.  I opted to replace it with ellipsis=`500` modifier to limit the content output to first 500 chars followed by ellipsis to suit my preference.
  2. Also in $blog_listing, getPage snippet uses @blog properties set. This set does not exists so the default property set will be used instead. I think idea is to create a blog property set within getPage snippet to override the default property settings in easy way, if customization is needed.

Commenting on the posts are not possible.  This need to be setup by yourself and will require Quip extra. that part is not covered by this article. One has to go back to modx documentation’s tutorial section.



factory function?

JavaScriptやPHPで、Function Factoryという言葉を見るのだが、これは共通するパターンのFunctionを生成するためのFunctionということで、例えば

$double = function($x){
    return $x*2;
};

$triple = function($x){
    return $x*3;
};

$quadruple = function($x){
     return $x*4;
};

なんてのは、三つのfunctionを定義していても、よく見ると、2,3,4とかける数字が違うだけで、あとはまったく同じパターン。 このようなfunctionの記述を効率よく行うために

// This is function factory
$create_multiplier = function($y){
    return function($x) use ($y) {
        return $x * $y;
    };
};
//use the function factory to create three functions.
$double = $create_multiplier(2);
$triple = $create_multiplier(3);
$quadruple = $create_multiplier(4);

というような書き方をするテクニック。肝心な部分の記述は一回で済むためコードの管理も簡単になる。

上のコードは返すコードのなかで、$xを認識させるため、 use ( $x )というクローズをいれているが、PHP7.4 からPHPでもアローファンクションが使えるようになり、これだとuse というkeyword無しで、外側で設定されている変数を認識するようになる。ので、

$create_multiplier = function($y){ return fn($x)=>$x*$y;};

//use function factory to create three functions.

$double = $create_multiplier(2);
$triple = $create_multiplier(3);
$quadruple = $create_multiplier(4);

と、ファクトリーの部分の記述がすっきりする。

さらにこの上位のファンクションもアローファンクションで書いてしまうと

$create_multiplier = fn($y)=>fn($x)=>$x*$y;

となり、 プロのコーディングでアローが二つも三つもかさなるような記述が時々でてくるのだが、そろそろ読解がしんどくなってくるので、後で読み返してわかる記述方法としては、よし悪しかなあ。

Week number confusion

Just encountered this problem when I was talking with my colleague.  He thought this week was week 43 but it actually was 42 on my calendar.  Turned out, there are two ways to look at week number.

First one is to simply take January first as a start of week one.  In case of 2021, January 1 is Friday.   depending of what you think as a first day of week, this year’s week 1 is only 2 days long or 3 days long, then Week 2 will start on either January 3rd(Sunday) or January 4th (Monday)

Excel function =WeekNum()  uses this approach.

Then there is a week number definition by ISO 8601.  According to ISO,  Week 1 is the first week of the year that has more than 4 days in a week.  Further more, first day of week will start on Monday.

With this definition, January first of 2021 does not qualify as a  week number 1.  A week starts on January 4th(Monday) is week number 1.

Excel also has function to calculate this as   =ISOWeekNum()

When I first turn on week number display on Outlook,  it showed the week number based on ‘January 1 as week 1’ approach.   This is not correct on many occasion. It appears majority of business now uses ISO week number.   You can change the settings in Outlook calendar to correct this.

In Outlook, go to File then select ‘Option’ then select ‘Calendar’  In Worktime  section, change ‘First day of week’ to ‘Monday’ then First Week of Year from ‘Starts on Jan 1’ to ‘First 4 day week’

Trying to code ISO weeknumber in typescript turned out to be a fun project but that is another story..

Layoffされていて思ったこと

実は去年の4月中旬から7月中旬までレイオフされていた。会社によってはFurloughといったりするが、要は一時解雇。 給料は出ない。保険も一部カバーされなくなる。その代わり、と言っちゃなんだが 失業保険をもらえる’権利’が生ずる。 現在の米国の失業保険は週に360ドルだが、 Covid-19が猛威を振るい始めた段階で、4月から7月にかけては一時的に週に600ドルの特別手当がつくようになった。 なので、週にもらえる手当が960ドルだ。月に換算すると4,114ドル、日本円に換算すると約43万円。自分の場合はすでに子供は自立し、家の支払いも終わっているから、これだけ支給されれば生活にはこまらなかったが、 色々と考えることがあった。

1)退職の時期。 自分は日本にいたらすでに退職の年齢に達している。アメリカの場合は退職のタイミングは自分で決めるので、年金を受け取らないことによるペナルティが発生する71歳ぎりぎりまで働くことは可能なのだ。 とは言ってもそこまで働くつもりはあまりなく、 今開発中の製品が生産に移った時点で辞めようと考えていたのだが、 今回仕事をせずに過ごしてみて、少し考えが変わった。 色々習い事をしたり、趣味に時間が取れるのはうれしいのだが、なんともいえないすかすか感が漂う。 まだ引退するには早いかなあ、と思ってしまったのは事実。

2)自分の働く会社は一時キャッシュフローが全くの0になってしまったので、従業員の数を25%くらいにまで落とした。 2か月ほどで50パーセントまで戻したが自分はその勘定に入っていない。職種を考えると当たり前なのだが、給料がもらえないということより、自分が必要とされていないという疎外感のほうが精神的にきつかった。

というわけで退職後の生活を本当にどうすれば気持ちの健康を保てるのか、ということを考える良い機会になった。



ありがたいことに米国人の上司が自分の年季はあと一年くらいしかないということを知りながら、呼び戻してくれた。

最終的に呼び戻されたのは全従業員の2/3で、 残りは解雇。 それから3か月たったが仕事の流れに支障がないといえばウソになる。自動車業界というのは恐ろしいところで、2か月間生産がストップしたため市場在庫が底をつき、これを埋める形で生産の量はほぼ通常に戻ってしまったどころか、あちこちで部品の欠品が発生し、今や生産を維持するために毎日が火消し状態。単純に考えても仕事の量が50パーセント増えたのに、これだ。 えらいことである、

と 書いたのが1年前、 そのころは2021年の夏も過ぎればこの状況収まっているのだろうと思っていたのだがこれがとんでもない誤算。

まずコロナ騒ぎがおさまっていない。アメリカにしてもワクチンの接種率が頭打ちになってしまった。ワクチンに不安を持った層を共和党が煽った結果だが、アメリカという国民は科学や合理性を信じていない輩が半分ちかくいる、これが簡単に騙される、ということを改めて痛感した。 FaceBook/Twitter/youtube などにあふれているFake Newsにいとも簡単に乗せられている。これらのSNSは似たような記事をお勧めに載せるようにできているので、嘘でもどんどん信じるようにできているようだ。

それはともかく。

部品欠品の状況が一向に収まらない。これはアジアの生産拠点などが順繰りにコロナで閉鎖されたりすることによってSupply Chainが滞ってしまっていることが原因だが、それにより、各自動車メーカーが減産を余技なくされている。

自動車は何千点の部品で構成されているので一つでも欠品すると自動車として完成しないのだ。 困ったことに、全体的に減産しているので余っている部品は在庫がふくらみ、業者にとっては踏んだり蹴ったりである。



Hyperbolic function on Casio fx-991EX

There is no dedicated HYP key to call up cosh() or sinh() function in Casio fx-991EX.   This is a stern contrast to Casio fx-115ES keyboard.  It does not mean you cant use the hyperbolic funtction on fx-991EX

Hit “OPTNOption” key then select “Hyperbolic Func”

You need to be in “Calculate” mode to see this option, so for repeatability,

Hit menu, select 1.   Hit OPTNOption, select 1.

This calculator is obviously not RPN.  The calculator uses “natural notation” format.  It basically let you create equation and then evaluate the answer.  No concern on intermediate calculation.  Just answers, and it is really a wonder that you can get those devices for less than $20.
